Shuttle Barebone slim XH810 - Barebone - Intel Socket 1851 (Core Ultra 100&200)
H810 - DDR5 - DisplayPort - HDMI
Brand: Shuttle
SKU: XH810
$443.88
Price as listed. Shipping charges calculated at checkout.
In stock
Do you have any question about this product or its specs? Want to know more? Click here to contact our pre-sales consultant and make the right purchase.
NOTE: The information below is provided for your convenience only; the accuracy of the specifications cannot be guaranteed. However, if necessary, please check with us before purchasing. Data provided by 1 World Sync.
Design
Chassis type
3.5L sized PC
Product colour
Black
Cooling type
Active
LED indicators
Yes
Cable lock slot
Yes
Cable lock slot type
Kensington
VESA mounting
Yes
Product type
PC barebone
Processor
Built-in processor
No
Processor manufacturer
Intel
Network
Ethernet LAN
Yes
Wi-Fi
No
LAN controller
Intel I226-LM, Intel® I219-LM
Power
Power supply type
External AC adapter
Power supply
120 W
Number of power supply units
1
AC input voltage
100 - 240 V
AC input frequency
50/60 Hz
AC adapter output voltage
19 V
AC adapter output current
6.32 A
Performance
Motherboard form factor
mini ITX
Motherboard chipset
Intel H810
Processor socket
LGA 1851 (Socket V1)
Number of processors supported
1
Compatible processor series
Intel Core Ultra (Series 2)
BIOS type
AMI EEPROM
Trusted Platform Module (TPM)
Yes
Trusted Platform Module (TPM) version
2.0
Audio chip
ALC 888S
Packaging content
Power cord included
Yes
AC adapter included
Yes
Quick start guide
Yes
Drivers included
Yes
Graphics
On-board graphics card
Yes
Graphics card family
Intel
Audio
Built-in speaker(s)
No
Ports & interfaces
USB 2.0 ports quantity
4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
1
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
2
HDMI ports quantity
2
HDMI version
2.0/2.1
VGA (D-Sub) ports quantity
0
DisplayPorts quantity
1
DisplayPort version
1.4a
Microphone in
Yes
Headphone outputs
1
Ethernet LAN (RJ-45) ports
2
Serial ports quantity
3
DC-in jack
Yes
Storage
Storage drives installed
No
Supported storage drive types
HDD & SSD
Storage drive sizes supported
2.5,3.5,M.2 "
M.2 SSD size
2280 (22 x 80 mm)
Memory
Internal memory installed
No
Memory slots type
SO-DIMM
Number of memory slots
2
Maximum internal memory
96 GB
Supported memory clock speeds
5600 MHz
Supported memory types
DDR5-SDRAM
Memory channels
Dual-channel
Memory voltage
1.1 V
ECC
No
Non-ECC
Yes
Weight & dimensions
Width
238 mm
Depth
200 mm
Height
72.5 mm
Weight
1.9 kg
Package weight
3.2 kg
Technical details
Compliance certificates
Federal Communications Commission (FCC), CE, UKCA, BSMI, RCM, VCCI, RoHS
Sustainability
Sustainability certificates
ENERGY STAR, ErP
Operational conditions
Operating temperature (T-T)
0 - 50 °C
Operating relative humidity (H-H)
10 - 90 %
Other features
Country of origin
China
Logistics data
Harmonized System (HS) code
84733080
Ident
Manufacturer ID
XH810
EAN/UPC
0887993008110
Shuttle Barebone slim XH810 - Barebone - Intel Socket 1851 (Core Ultra 100&200) - H810 - DDR5 - DisplayPort - HDMI
