ZYXEL WAC500H - WIRELESS ACCESS POINT
NOTE: The information below is provided for your convenience only; the accuracy of the specifications cannot be guaranteed. However, if necessary, please check with us before purchasing. Data provided by 1 World Sync.
General
Maximum data transfer rate
1200 Mbit/s
Maximum data transfer rate (2.4 GHz)
300 Mbit/s
2.4 GHz
Y
Maximum data transfer rate (5 GHz)
866 Mbit/s
5 GHz
Y
Security algorithms
EAP,SNMP,WEP,WPA,WPA2-Enterprise,WPA2-PSK,WPA3
AC input voltage
100 - 240 V
Input current
0.3 A
AC input frequency
50/60 Hz
Placement
Wall
Product colour
White
Certification
FCC 15C, FCC 15E; ETSI EN 300 328, EN 301 893; LP0002, EN 60601-1-2 FCC 15B, EN 301 489-1; EN 301 489-17, EN55022, EN55024, EN61000-3-2/-3, BSMI CNS13438 EN 60950-1, IEC 60950-1; BSMI CNS14336-1
Antenna type
Internal
Antenna gain level (max)
4 dBi
Zyxel WAC500H. Maximum data transfer rate: 1200 Mbit/s, Maximum data transfer rate (2.4 GHz): 300 Mbit/s, Maximum data transfer rate (5 GHz): 866 Mbit/s. Security algorithms: EAP, SNMP, WEP, WPA, WPA2-Enterprise, WPA2-PSK, WPA3. AC input voltage: 100 - 240 V, Input current: 0.3 A, AC input frequency: 50/60 Hz. Placement: Wall, Product colour: White, Certification: FCC 15C, FCC 15E; ETSI EN 300 328, EN 301 893; LP0002, EN 60601-1-2 FCC 15B, EN 301 489-1; EN 301.... Antenna type: Internal, Antenna gain level (max): 4 dBi
| Estimate Gross Weight | 0.424 |
|---|
Get not only wireless but wired and PoE connectivity, too
The Zyxel WAC500H is designed for per-room deployment scenarios. It turns an Ethernet wall plate into not only a wireless access point to provide WiFi service but also a Gigabit switch with PoE, powering a VoIP phone for last-mile network services.
Featuring NebulaFlexTM Pro, the WAC500H can be managed through a local web management interface, hardware controller, or with a one-year free license on the Nebula cloud management platform.
Versatile mounting options
The versatile yet low-profile mounting design allows the access point to blend seamlessly and tastefully into any decor while mounted directly on an outlet box, in an out-of-the-way location, or even simply on a desktop.
More than WiFi
As well as providing superb WiFi, the WAC500H supports 24/7 wired and PoE connectivity for mobile Point-of-sale (POS) applications for restaurants, bars, and cafés.
Work from home like a Pro!
Supporting the 802.11ac Wave 2 standards, the WAC500H provides fast and reliable connectivity with full support of video conferencing, secure data transfer and seamless connection of multiple devices.
The ΓÇ£RF FirstΓÇ¥ and MU-MIMO technology of WAC500H ensure the high-speed connectivity. And, the two downlink Gigabit Ethernet ports allow an easy connection to a wired printer or powering up a VoIP phone effortlessly.
Most flexible management
The WAC500H features NebulaFlex Pro technology, which allows the AP to be run in three different modes - standalone, controller, or Nebula Cloud Networking platform based on the need of each user. For a straightforward network it can be run in standalone mode, for a complex one that requires advanced features it can be run with an on-premises controller. And, Nebula cloud networking is designed to satisfy all situations with great scalability, feature-rich, and central management.
