Arctic P14 14cm PWM Computer Fan Fluid Dynamic 200-1700 RPM
200 - 1700 RPM - PWM - 72.8 CFM - 123.76 m3/h - 12 V DC - 4-pins - 194 g - White - Pressure optimized PWM Computer Fan White Fluid Dynamic 200-1700 RPM
Brand: Arctic
SKU: ACFAN00222A
$83.88
Price as listed. Shipping charges calculated at checkout.
In stock
Do you have any question about this product or its specs? Want to know more? Click here to contact our pre-sales consultant and make the right purchase.
NOTE: The information below is provided for your convenience only; the accuracy of the specifications cannot be guaranteed. However, if necessary, please check with us before purchasing. Data provided by 1 World Sync.
General
Type
Fan
Fan diameter
14 cm
Rotational speed (min)
200 RPM
Rotational speed (max)
1700 RPM
Noise level
0.3 sone
Maximum airflow
72.8 cfm
Airflow
123.76 m³/h
Maximum air pressure
2.4 mmH2O
Bearing type
Fluid Dynamic Bearing (FDB)
Voltage
12 V
Width
140 mm
Depth
140 mm
Height
27 mm
Product colour
White
ARCTIC P14 PWM Pressure optimized 140 mm Fan with PWM. Type: Fan, Fan diameter: 14 cm, Rotation speed (min): 200 RPM, Rotation speed (max): 1700 RPM, Sound level: 0.3 sone, Maximum air flow: 72.8 cfm, Air flow: 123.76 m³/h, Maximum air pressure : 2.4 mmH2O, Bearing type: Fluid Dynamic Bearing (FDB). Voltage: 12 V. Width: 140 mm, Depth: 140 mm, Height: 27 mm. Product colour: White
| Estimate Gross Weight | 0.207 |
|---|
https://www.arctic.de/en/P14-PWM/ACFAN00222A
The P14 PWM features completely redesigned fan blades and is optimised for high static pressure. Thanks to this, it is especially effective when used on heatsinks and in situations with higher air resistance.The wide RPM range from 200 to 1700 RPM can be regulated steplessly via PWM.The newly developed motor with a low coil temperature significantly increases the life span of the fan. Therefore we have extended the warranty to 10 years.
The P14 PWM features completely redesigned fan blades and is optimised for high static pressure. Thanks to this, it is especially effective when used on heatsinks and in situations with higher air resistance.The wide RPM range from 200 to 1700 RPM can be regulated steplessly via PWM.The newly developed motor with a low coil temperature significantly increases the life span of the fan. Therefore we have extended the warranty to 10 years.
- Optimised for static pressure
- Ideal choice on heatsinks, radiators and (partly-) covered case vents
- Push- or pull-configuration
- PWM signal adjusts fan speed
- Newly developed, very quiet motor
- Extended life span
